Freeman Street Market, Grimsby
| Capacity | 197.76 kWp |
| Predicted Output | 151,681 kWh |
| Panel Type | LG and Upsolar |
| Inverters | SMA Tripower |
| Roof Type | Metal Trapezoidal |
| Location | Grimsby |
A 197.76kWp solar pv system installed on the east and west roof faces of Grimsby Freeman Street Market using Upsolar and LG panels and Sunny Tripower inverters. The system was installed in 4 stages in November 2011, February 2012, March 2014 and February 2015 with the majority of the energy produced being consumed within the market.
The panels feed into 12 SMA three-phase inverters ranging from 8kWp to 17kWp and all reporting to SMA's online monitoring system, Sunny Portal.
Cafe, Headingley
| Capacity | 9.75 kWp |
| Predicted Output | 7,454 kWh |
| Panel Type | Schott |
| Inverter | Sunny Tripower 10,000TL |
| Roof Type | Artificial Slate |
| Location | Headingley, Leeds |
9.75 kWp solar pv system installed in Novermber 2011 on the roof of the Voodoo Cafe in Headingley, Leeds. Careful design was needed to mitigate shading issues.
Artist Studio, Leeds
| Capacity | 10 kWp |
| Predicted Output | 8,711 kWh |
| Panel Type | Hyundai |
| Inverters | SMA Tripower |
| Roof Type | Slate |
| Location | Central Leeds |
A 10kWp solar PV system installed on the South and East slate roofs. Rising energy bills at the studio prompted the owners to get in touch with us to design a besoke PV solution. At over 3 stories high and on a slate roof, this installation presented an interesting challenge.
A single inverter with dual tracking capability allows both arrays to operate independently of each other at maximum efficiency.
